In the field, a solo hunter typically scans with a handheld binocular or monocular, then switches to a riflescope after locating a target. In a two-person team, one hunter spots game while the other prepares to shoot.

However, this workflow has its drawbacks. Calling out distances can lead to misunderstandings and repeated communication, while raised voices may alert nearby game. Solo hunters also have to switch constantly between devices, estimate distances and handle ballistic calculations. After spotting an animal through a binocular, relocating the same target through a riflescope can take valuable time—especially when several potential targets are present.

CrossLink is designed to solve these exact problems.

Two compatible Pixfra devices connect wirelessly to share laser rangefinder (LRF) data, ballistic information and live footage in real time. Measurements taken with the spotter’s Draco binocular are sent directly to the shooter’s Cetus riflescope, where the Draco live-view stream can also be displayed.

No shouting, no guessing and no constant switching between devices.

What Is Pixfra CrossLink?

Think of CrossLink as a direct wireless bridge between a compatible Pixfra multispectral binocular, such as Draco, and a compatible thermal riflescope, such as Cetus.

• Draco acts as the sender. It scans the surroundings, measures distance with its laser rangefinder, calculates ballistic offsets and shares its live digital and thermal view.
• Cetus acts as the receiver. It displays the transmitted range, calculated ballistic holdover and real-time feed from Draco. The riflescope’s original reticle remains unchanged.
• The devices connect directly over Wi-Fi. No external router or smartphone is required.

Here is how CrossLink works in practice:

Imagine scanning a hillside with your Draco binocular and spotting a deer 800 yards away. Pressing the LRF button sends the measured range directly to your partner’s Cetus riflescope. The scope displays the distance, calculated ballistic holdover and live-view feed from Draco.

The shooter does not need to repeat the rangefinding process, search for the target without guidance or calculate the holdover manually. The displayed information can be used to make the appropriate adjustment while retaining the standard riflescope reticle.

One hunter spots while the other prepares to shoot. Ranging and ballistic information stay synchronized automatically.

How CrossLink Improves Your Hunting Experience

Conventional hunting workflows can be slowed down by cumbersome device handling, ambient noise and inefficient communication between hunting partners.

CrossLink allows a Draco binocular to send range measurements, ballistic calculations and live thermal imagery directly to a Cetus riflescope.

Key advantages include:

• Save valuable time between spotting game and preparing for a shot.
• Reduce manual input errors with automatic ballistic calculations.
• Add ranging and ballistic capabilities to a Cetus without a built-in rangefinder.
• Stay focused on searching for and tracking game.
• Enjoy a simpler workflow without repeatedly consulting complicated ballistic charts.

Bottom line: CrossLink allows two compatible Pixfra devices to work as one connected system. Cetus owners can add laser-ranging and ballistic-calculation capabilities by pairing their scope with a Draco, without replacing the riflescope with a new rangefinder model.

Which Pixfra Devices Support CrossLink?

CrossLink currently supports the flagship Draco and Cetus combination. Support for additional Pixfra binoculars, monoculars and riflescopes may be added in future firmware releases.

If you already own a compatible Draco and Cetus combination, a firmware update can unlock CrossLink without requiring additional hardware.

How to Set Up and Use Pixfra CrossLink

Draco: Sender Setup

1. Open the Main Menu.
2. Select Wi-Fi.
3. Choose either the 2.4 GHz or 5 GHz band.
4. Confirm that the Wi-Fi hotspot is active.

Cetus: Receiver Setup

1. Open the Main Menu.
2. Select CrossLink, then turn it on.
3. Open Device Search and scan for available Draco devices.
4. When connecting for the first time, enter the Draco Wi-Fi password and complete the connection.
5. Set Sub-Display to ON or OFF, depending on whether you want the Draco live-view feed to appear on the Cetus.

Once connected, every range measurement taken with the Draco is updated on the Cetus in real time, together with the corresponding ballistic calculation. You can also switch to live-view mode to see what the Draco is displaying.

Frequently Asked Questions

Why can’t I find the CrossLink menu on my device?

First, confirm that you are using a supported combination: a Draco binocular as the sender and a Cetus riflescope as the receiver.

If your devices are compatible but the CrossLink option is missing, update the Draco firmware to version 260806 or later and the Cetus firmware to version 260805 or later. Both devices should be running the latest available firmware.

Visit the Pixfra Download Center

Why isn’t my Cetus displaying LRF data?

Make sure CrossLink is enabled and that the Cetus has successfully connected to the Draco. Then activate the LRF function on the Draco. The range data should appear on the Cetus screen.

Can I connect third-party optical devices through CrossLink?

No. CrossLink is a proprietary Pixfra feature and is not compatible with devices manufactured by other brands.

Which device combinations currently support CrossLink?

CrossLink currently supports a Draco binocular as the data sender and a Cetus riflescope as the receiver.

Can one Draco connect to multiple Cetus riflescopes?

A one-to-one connection is currently recommended to maintain stable data transmission.

Can one Cetus connect to multiple sender devices simultaneously?

No. A Cetus receiver can maintain only one active CrossLink connection with one Draco binocular at a time.

Does CrossLink support continuous LRF transmission?

Yes. CrossLink supports both triggered and continuous LRF modes. When LRF is active on the Draco, ranging information and live-view footage can be transmitted to the paired Cetus while the devices remain connected.

What is the reliable wireless operating distance?

The stable effective transmission distance is approximately 3 meters. For the most reliable connection, keep the two devices within arm’s reach during use.

A Final Note

What makes thermal optics genuinely useful in the field is often not a headline specification, but how well the small practical details fit into a real hunting workflow.

CrossLink is not technology for technology’s sake. It addresses a specific field challenge: sharing laser range measurements and target awareness between compatible devices, whether you hunt alone or with a partner.

Existing Draco and Cetus owners can unlock CrossLink through a firmware update without purchasing additional hardware, making their current setup more connected and efficient.

For hunters building a Pixfra system, CrossLink provides another reason to pair compatible devices. One LRF-equipped binocular can send information directly to the riflescope, reducing duplicated hardware and unnecessary steps.

Update your firmware and try CrossLink on your next hunt.
